SL Model Features Include:
- 230 Volt 1 Phase
- Heavy Duty Modular Formed Steel Frame
- Easy Access Pump Module Hood
- Durable Hi-Gloss Powder Coated Paint
- Ground Spacing Legs
- Stainless Steel Combustion Chamber Wrapper
- Fuel Efficient Combustion Chamber
- Standing Pilot
- Quick Coil Access
- Exclusive Chamber Insulation System
- Heating Coil Constructed of ASTM A53 Schedule 80 Steel Pipe
- Heavy Duty Electro Plated Fittings
- Adjustable Temperature Control
- Pressure Relief Valve
- Belt Driven Pump
- Industrial Strength Electric Motors
- Insulated Wand with 4000 PSI Trigger Gun
- Trigger Gun Control
- 0° and 15° Quick Couple Stainless Steel Nozzles
- Wire Braid Discharge Hose
- Corrosion Proof Polyethylene Float Tank with Chemical Metering
- High Pressure Soap
- Low Water Shut-Off Protection
- Watertight Electrical Panel
- Calibrated Detergent Metering Valve
- Draft Diverter
- ETL Listed
- Time Delay Shutdown
- Hour Meter
- 25° & 40° Quick Couple Stainless Steel Nozzles
Options for the SL Model:
- Elecrtonic Ignition
- 2-Way Remote (Limit of One Remote)
- Soap Solenoid
| Model | 17-416 | 17-423 | 17-423 | 17-423 |
|---|---|---|---|---|
| Flow Output (GPM) | 4 | 4 | 4 | 4 |
| Pressure Ratings (PSI) | 1600 | 2300 | 2300 | 2300 |
| Max Output Temperature | 210° | 210° | 210° | 210° |
| Cleaning Comparison Index | 15,112 | 18,118 | 18,118 | 18,118 |
| Motor Horsepower | 4 | 6 | 6 | 8 |
| Volt | 230 | 230 | 230 | 440 |
| Amp | 20 | 30 | 20 | 15 |
| Phase | 1 | 1 | 3 | 3 |
| Input BTU's - LP | 332,000 | 332,000 | 332,000 | 332,000 |
| Input BTU's - NG | 415,000 | 415,000 | 415,000 | 415,000 |
| Fuel Consumption (LBH) (2) | 12.35 | 12.35 | 12.35 | 12.35 |
| LP Tank Minimum Size | 100# | 100# | 100# | 100# |
| Stack Size | 10" | 10" | 10" | 10" |
| Discharge Hose | 3/8" x 50' | 3/8" x 50' | 3/8" x 50' | 3/8" x 50' |
| Length | 45" | 45" | 45" | 45" |
| Width | 26" | 26" | 26" | 26" |
| Height | 47" | 47" | 47" | 47" |
| Approximate Weight (LBS) | 620 | 650 | 650 | 650 |
| Model | 17-430 | 17-430 | 17-430 | |
|---|---|---|---|---|
| Flow Output (GPM) | 4 | 4 | 4 | |
| Pressure Ratings (PSI) | 3000 | 3000 | 3000 | |
| Max Output Temperature | 210° | 210° | 210° | |
| Cleaning Comparison Index | 20,693 | 20,693 | 20,693 | |
| Motor Horsepower | 8 | 7.5 | 7.5 | |
| Volt | 230 | 230 | 440 | |
| Amp | 40 | 25 | 15 | |
| Phase | 1 | 3 | 3 | |
| Input BTU's - LP | 332,000 | 332,000 | 332,000 | |
| Input BTU's - NG | 415,000 | 415,000 | 415,000 | |
| Fuel Consumption (LBH) (2) | 12.35 | 12.35 | 12.35 | |
| LP Tank Minimum Size | 100# | 100# | 100# | |
| Stack Size | 10" | 10" | 10" | |
| Discharge Hose | 3/8" x 50' | 3/8" x 50' | 3/8" x 50' | |
| Length | 45" | 45" | 45" | |
| Width | 26" | 26" | 26" | |
| Height | 47" | 47" | 47" | |
| Approximate Weight (LBS) | 670 | 670 | 670 |
