Standard Features Include:
- 115 Volt 1 Phase (16-310 ES)
- 230 Volt 1 Phase (16-325ES / 16-423ES /
16-430 ES / 16-525 ES) - Heavy Duty Tubular Steel Frame
- Burable Hi-Gloss Powder Coated Paint
- Ground Spacing Legs with foot Pads
- Painted Combustion chamber Wrapper
- Fuel Effecient Combustion Chamber
- Standing Pilot
- Quick Coil Access
- Exclusive Chamber Insulation System
- Heating Coil constructed of ASTM A53 Schedule 80 Steel Pipe
- Heavy Duty Electro Plated fittings
- High Limit Temperature Control
- Pressure Relief Valve
- Belt Driven Pump
- Industrial Strength Electric Motors
- Insulated Wand with 4000 PSI Trigger Gun
- Trigger Gun Control
- 0° and 15° Quick Coupled Stainless Steel Nozzles
- 3/8″ x 50″ High Pressure Hose Assembly with Safety Hose Guards
- Wire Braid Discharge Hose
- Low Water Shut-Off Protection
- Watertight Electrical Panel
- Draft Diverter
Options for ES Models:
- Four Wheel Kit (K16-0001)
- Propane Tank Braket (K16-0002)
- Soap Solenoid
| Model | 16-310 | 16-325 | 16-423 | 16-430 | 16-525 |
|---|---|---|---|---|---|
| Flow Output (GPM) | 3 | 3 | 4 | 4 | 5 |
| Pressure Ratings (PSI) | 1000 | 2500 | 2300 | 3000 | 2500 |
| Max Output Temperature | 210° | 210° | 210° | 210° | 210° |
| Cleaning Comparison Index | 8960 | 12672 | 18119 | 20693 | 22613 |
| Motor Horsepower | 2.3 | 5 | 6 | 8 | 8 |
| Volt | 115 | 230 | 230 | 230 | 230 |
| Amp | 20 | 20 | 30 | 40 | 40 |
| Phase | 1 | 1 | 1 | 1 | 1 |
| Input BTU's | 256,000 | 256,000 | 332,000 | 332,000 | 352,000 |
| Fuel Consumption (GPH) | 9.52 | 9.52 | 12.35 | 12.35 | 13.09 |
| Burner Fuel Tank Capacity | 7.4 | 7.4 | 7.4 | 10.4 | 10.4 |
| Stack Size | 8" | 8" | 10" | 10" | 10" |
| Length | 39" | 39" | 39" | 39" | 39" |
| Width | 26" | 26" | 26" | 26" | 26" |
| Height | 46" | 46" | 46" | 46" | 46" |
| Approximate Weight (LBS) | 430 | 445 | 630 | 650 | 670 |
